Specifications
Specifications| Network interface | ● 24 10/100Mbps RJ45 PoE ports, of which 17-24 ports can support 100M ultra-long distance, 500 meters away from transmission (used with long-distance splitter) ● 2 10/100/1000Mbps RJ45 ports ● 1 Gigabit SFP Combo port |
| protocol | ● IEEE 802.3i、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3z、 IEEE 802.3ab、IEEE 802.3af、IEEE 802.3at |
| Performance Specifications | ● Backplane bandwidth: 8.8Gbps (non-blocking) ● Packet forwarding rate: 6.5Mpps ● MAC address table: 8K ● Forwarding mode: store and forward |
| LED indicator | ● 26 Link/Act indicators ● 24 PoE indicators ● 1 Power light |
| PoE Pin | ● 1/2( +) ，3/6(-) |
| Power Supply | ● Single port maximum output power: 30W ● The maximum power of the whole machine: 250W |
| Size | ●（ LxWxH ）：440mm*180mm*44mm |
| Environmental Specifications | ● Working temperature: 0°C~40°C ● Storage temperature: -40℃ ~ 70℃ ● Working humidity: 10%~ 90% RH without condensation ● Storage humidity: 5%~90% RH without condensation |
| safety standard | ● CE/ROHS/FCC/CCC |
